Combined wind capacity high efficiency filter

Combined wind capacity high efficiency filter

High efficiency filter, without clapboard design, combined wind capacity HEPA filter small particles with excellent filtration efficiency, mainly to capture the 0 to 3um of air dust particles, modular HEPA filter designed for maximum air flow can be up to 4200m3 / h, mainly in the amount of wind environment.

n Material:

Two filter media: H13-H14 glass fiber filter paper;

Filtration efficiency: H13-H14, H13 99 97-99 99% @ 0 3μm, H14 99 995-99 999% @ 0 3μm (of MPPS);

2 frame material: aluminum folding frame, galvanized steel frame, stainless steel frame, plastic frame;

Two sealing strip: chloroprene rubber

Generally separated: generally two separated surrounded by three separated six sides, four separated octahedral, five separated from the surface;

2 Filter size: width (w): 287 mm, 490 mm, 595 mm, 610 mm; general height (H): 305mm, 595 mm, 610 mm; general depth (D): 295mm;

n Application of occasions:

Terminal filter of two air conditioning units, air volume air purification equipment
