You are here：Home >> Products
HLB Clean Laminar Booth
===Features===
◆Can be lifted over the process point that requiring high cleanliness,
to meet the requirements of local high cleanliness
◆Outer casing can be made of sandwich panel, cold-rolled steel or
stainless steel sheet
◆Can be used alone, also be composed of multiple parallel into a
banding clean laminar flow
◆Less investment, fast effect, easy installation, low operating costs
◆Cleanliness: FS209E Class 100 / ISO Class 5
◆Mean Stream Velocity: 0.35~0.55m/s
◆Noise: ≤64dB(A)
===Application===
◆Mainly used in clean and sterile operating environment of electronics,
biology, medicine, food, precision instruments, provide high cleanliness
of the local environment
- ===Common specifications===
| Model | Rated Air Flow (m3/h) | Dimensions | Working Area (mm) | HEPA Outfit | Power Supply and Dissipation | |
| L×W×H (mm) | ||||||
| HLB1220/610 | 1200 | 1360×740×850 | 1220×610 | 610×610×150 (mm) 2pcs | AC 1Ф-220V/50Hz (1Ф-110V/60Hz) | 1.0kW |
| HBL1220/915 | 1800 | 1360×1040×850 | 1220×915 | 915×610×150 (mm) 2pcs | 1.1kW | |
| HBL1220/1220 | 2400 | 1360×1360×850 | 1220×1220 | 1219×610×150 (mm) 2pcs | 1.3kW | |
| HBL2500/915 | 4800 | 3200×1040×600 | 2500×915 | 915×610×150 (mm) 4pcs | AC 3Ф-380V/50Hz (3Ф-200V/60Hz) | 1.8kW |
HEFIL makes various other models of HLB laminar booth not listed the above table. Please consult with us if you need.
